Hydraulic Aluminum Steel Coil Slitting Line Rolled Steel Sheet Slitting Machine For Construction Use

Specifications:

Technical data of slitting line.

Major technical parameter:

1) Processible coil plate: cold rolling steel, prepainted, picking coil plate (b≤450Mpa s≤260Mpa).

2) Thickness of coil plate: 0.3-3.0mm

3) Width of coil plate: 400-1600mm

4) Coil plate I.D: Ф508-Ф610mm(add rubber pad)

5) Coil plate O.D: ≤Ф1600mm

6) Weight of coil plate: 15T

7) Finished product coil I.D: Ф508mm

8) Finished product coil O.D: ≤Ф2000mm

9) Max weight of finished products coil: ≤15T

• Slitting speed: 0-120m/min
• Width precision of slitting and dividing: ±0.05mm (plate thickness: 0.3-1.0mm)

±0.1mm (plate thickness: 1.1-3.5mm)

11) Precision of dividing straight line: 0.2mm/m

12) Slitting burr: ≤0.05δmm

13) Min width of slitting: 35mm
14) Slitting strips.: 0.3-1.0mm---20 strips, 3mm≤15 strips

15) Width range of scrap: 2-15mm

16) Scrap Max. weight: ≤150kg/coil

17) Scrap amount: 2pcs

18) Motor power: about300kw

19) Standard height: 1000mm

Description:

Fashionable design BLFM.

producing process:

Competitive Advantage:

1), Q: Do you have after sales support?

A: Yes, we are happy to give advice and we also have skilled technicians available across the world. We

need your machines running in order to keep your business running.

2), Q: How do your machines compare with other big companies in this market?

A: We are up to date with the latest technology and improve our machines accordingly

3), Q: How does your factory do regarding quality control?
A: Quality is priority.bluesteel People always attach great importance to quality control from the very

beginning to the end of the production. Every product will be fully assembled and carefully tested before

it's packed for shipment.

4), Q: Do you sell only standard machines?

A: No, most of our machines are built according to customers specifications, using top brand name

Hangzhou Bluesteel Machine Co.,Ltd

We are a manufacturer specialized in custom roll forming machinery. With our advanced techniques and experienced staff members, we can produce simple profiles as well as complex components with precision tolerances. Most of our main production staff members have about 10 years of experience, ensuring quality machinery and high values for our customers.

Our products are widely used in steel structure Construction, like roof and wall,and door or window,and supermarket ,warehouse  etc.

Advantages of Roll Forming:

Roll formed parts can have a variety of shapes, angles and curves. Many materials are suitable for our custom roll forming machines, which allows us to provide components and parts with a wide variety of plated, pre-painted and laminated materials to meet your roll forming needs. We design products that best meet specific needs.

bluesteel Machine’s mission is to provide the highest quality products as a competitive price, good in Quality, On-Time Deliveries, and Superlative Customer Support.

bluesteel Machine has become a reliable bridge between overseas customers and rollforming machines based on its riche professional experience in marketing steel products and providing services. The company persists in seeking global business partners, provides them solid service and keeps stable and reliance business modules.
